Riveting l Riveting Squeezers l Bench Mount
 |
Bench Models |
|||||
MODEL NO. |
YOKE THIKNESS INCHES (mm) |
REACH INCHES (mm) |
GAP INCHES (mm) |
WEIGHT (less power unit) LBS. (kgs.) |
|
8000CSA |
9-1/2 |
5 |
180 |
||
8000CSA |
12-1/2 |
5 |
220 |
||
8000CSA |
24-1/2 |
5 |
680 |
||
15KCSA |
9-1/2 |
5 |
183 |
||
15KCSA |
12-1/2 |
5 |
226 |
||
15KCSA |
24-1/2 |
5 |
686 |
||
C60B |
1-3/8 (34.9) |
6 (152.4) |
3-1/2 (88.9) |
27 (12.2) |
|
C90B |
1-5/8 (41.3) |
9 (228.6) |
3-1/2 (88.9) |
55 (25) |
|
*C120B |
2-3/8 (60.3) |
12 (304.6) |
4 (101.6) |
175 (79) |
|
*C180B |
2-3/4 (69.85) |
18 (457.2) |
4 (101.6) |
400 (182.8) |
|
110,001 |
Floor stand with FRL for 9/12" or 12-1/2" |
||||
A-KIT |
PEM Stand Off Kit |
||||
B-KIT |
PEM Stand Off Kit for longer studs |
||||
"C" Yokes Specs |
|||||
YOKE NUMBER |
REACH INCHES (mm) |
GAP INCHES (mm) |
"A" INCHES (mm) |
"B" INCHES (mm) |
THICKNESS INCHES (mm) |
C15 |
1-1/2 (38.1) |
1-1/4 (31.75) |
3-1/4 (82.55) |
3-3/4 (95.25) |
9/16 (147.27) |
C20 |
2 (50.8) |
1-1/4 (31.75) |
4 (101.6) |
3-7/8 (98.4) |
9/16 (14.27) |
C25 |
2-1/2 (63.5) |
1-1/4 (31.75) |
4-3/4 (120.65) |
4 (101.6) |
9/16 (14.27) |
C30 |
3 (76.2) |
1-1/4 (31.75) |
4-3/4 (120.65) |
4 (101.6) |
3/4 (19.05) |
Alligator Jaw Specs |
|||||
ALLIGATOR JAW |
"A" REACH INCHES (mm) |
"B" TOTAL GAP INCHES (mm) |
"C" CLOSED HEIGHT INCHES (mm) |
"D" ANVIL DIAMETER INCHES (mm) |
"E" CLEAREANCE STA. JAW INCHES (mm) |
A15 |
1-1/2 (38.1) |
1-5/8 (41.3) |
7/8 (22.2) |
1/2 (12.7) |
3/8 (9.5) |
A22 |
2-1/4 (57.15) |
2-1/8 (53.97) |
7/8 (22.2) |
1/2 (12.7) |
3/8 (9.5) |
A30 |
3 (76.2) |
2-1/8 (53.97) |
7/8 (22.2) |
1/2 (12.7) |
3/8 (9.5) |
